XRotor PRO 25A Circular (Black Color)- 30902022 HOBBYWING  [HW-30902022]

Effortless Installation

Motor could possibly be closely setup regarding the ESC, which notably simplifies wiring and
setting up the propulsion system.

Popular Choice

The mount is excellently appropriate probably the most utilized 16mm
(outer diameter) carbon fibre supply pipeline.

Excellent Protection

The included framework the ESC and motor mount has
exemplary dustproof and splash proof protection.

DEO Technology

The DEO (Driving effectiveness Optimization) technology applied
in to the ESC has many advantages:
● Active braking. Whenever reducing the throttle volume, the motor will
decelerate quickly. This function enables pilots to easier
perform all maneuvers like razor-sharp turns, altitude modifications, and
unforeseen braking.
● greater driving effectiveness, considerably longer journey time.
● Lower ESC temperature and a far more dependable procedure .
* various companies call this technology by different names;
“SimonK” calls it “Comp_PWM”, “BLHeli” calls it “Dampaning-light”
and Kontronik calls it “Active Freewheeling”.

A simple task to Use

Highly smart and adaptive standard settings like
auto-adjusting timing for simple procedure.

Item Specification

Product Number

Specifications

• Cont./Peak Current : 25A/40A
• LiPo Cells : 3-6S LiPo
• BEC manufacturing : No

Wires & Connectors

• Input Wires : Red-18AWG-300mm*1/Black-18AWG-300mm*1
• Output Wires : No
• Input Connectors : No
• Output Connectors : No

Features

• Throttle Range Calibration : Supported
• Stick Programming : Supported
• DEO : Supported
• OneShot Mode : not Supported
• Timing : Supported
• Light colors : perhaps not Supported
• Motor Rotation : perhaps not Supported

Size & Weight

• Size : 89.3x44.5x20.9mm
• Weight : 50.5g(w/ Engine Mount)
