Hobbywing HW-30901077 XRotor Micro 30A BLHeli_32 DShot1200 30901077 Drone System
Top end Hardware &
Original Third-generation BLHeli_32 Firmware
The utilizing superior 32-bit supply microprocessor (which runs at 48MHz),
introduced quality MOSFETs (Fairchild) & ceramic capacitors, 3-in-1 drive ICs,
3-ounce copper, 4 forms of PCBs, and third-generation BLHeli (BLHeli_32 firmware)
produces an ESC with a rise of functions & better performance particularly for FPV drones.
Hardware Generated PWM & Damped Light Mode
The ESC firmware uses gear produced engine PWM for smooth throttle effect and peaceful
procedure. Damped light does regenerative breaking, causing quickly motor retardation, and yes it
inherently additionally does active freewheeling.
Numerous Programmable Items
The initial BLHeli_32 firmware allows users to obtain linked four
ESCs toward FC flashed along with the Cleanflight/Betaflight
firmware via indication cables (in the ESCs) setting fundamental
parameters linked to ESCs simultaneously, upgrade the firmware
or modification high level parameters on the web besides.
A few Protections
Multiple protection functions like engine
lock-up security, heat protection,
low RPM power security, low-voltage
protection and current safety efficiently
prolong the solution life towards ESC.
Light-emitting Diode Indicator (essentially the XRotor 40A
BLHeli_32 has it) & Beacon Functionality
The light color linked to Light-emitting Diode indicator in to the ESC is adjustable.
The Beacon functionality, that could drive the engine to beep in the event throttle indication has
been zero for many time, efficiently assists finding lost crafts.
Specifications
- Cont./Peak active : 30A / 50A
- LiPo Cells : 2-5S Lipo
- BEC manufacturing : No
Wires & Connectors
- Output Wires : No cables but solder tabs
- Input Connectors : No
- Output Connectors : No
- Firmware : BLHeli_32
- ESC Programming : Supported
- Stick Programming : BLHeliSuite
- DEO : Supported
- Throttle volume Calibration : Supported
- Oneshot125 Mode : Supported
- Oneshot42 Mode : Supported
- MultiShot Mode : Supported
- Timing : Supported
- Motor Rotation : Supported
Size & Weight
- Size : 23.8x14.5x5.8mm
- Weight : 6g
